Bobcat T86 Compact Track Loader Specs & Information

Bobcat T86 Compact Track Loader

The Bobcat® T86 is the most powerful compact track loader we’ve ever built, delivering more usable engine and hydraulic horsepower than ever before.  The Bobcat T86 compact track loader features an optimized weight-to-horsepower ratio that ranks this vertical lift machine among the industry’s most powerful, maneuverable, efficient and productive in its size class.

Bobcat T86 Articles

Key Specifications & Add-ons

Radio Remote Control (SJC required) Optional
Reversing Fan Optional
Standard Display (includes keyless start) Standard
Speed Management Standard
Heated Cloth Air-Ride Seat Standard
LED Front and Rear Lights Standard
Joystick Control Standard
Air Conditioning Standard
Backup Alarm Standard
BICS System (Interlock) Not Applicable
Suspension Seat Standard
Two Speed Travel Standard
Auxiliary Hydraulics Standard
Bob-Tach Attachment System Standard
Power Bob-Tach Standard
Ride Control Optional
Horn Standard
Sound Option Standard
Dual-Direction Bucket Positioning Standard
Rated Operating Capacity (ISO) 3,800 lb
Operating Weight 12393 lb
Ground Pressure (Rubber) 4.8 psi
Auxiliary Std Flow 23.6 gal/min
Auxiliary High Flow 36.6 gal/min
Joystick Control Standard

Performance

Hydraulic System Pressure (Standard and High Flow) 3,500 psi
Hydraulic System Pressure (Super Flow) 4,061 psi
Hydraulic Standard Flow 23.6 gal/min
Hydraulic High Flow (optional) 36.6 gal/min
Hydraulic Super Flow (optional) 42 gal/min
System Relief @ Quick Couplers 3,450 psi
Auxiliary Std Flow Auxiliary High Flow
Auxiliary High Flow 36.6 gal/min
Rated Operating Capacity (ISO) 3,800 lb
Rated Operating Capacity 200 lb. Counterweight 3,950 lb
Rated Operating Capacity 300 lb. Counterweight 4,025 lb
Rated Operating Capacity 400 lb. Counterweight 4,100 lb
Rated Operating Capacity with Torsion 3,700 lb
Operating Capacity (50% of Tip) 5429 lb
Tipping Load 10857 lb
Operating Weight 12393 lb
Travel Speed 5.4 mph
Travel Speed (2-speed option) 10.4 mph
Ground Pressure (Rubber) 4.8 psi
Emissions Tier (EPA) Tier 4
Engine Cooling Liquid
Engine Fuel Diesel
Horsepower 105 hp
Turbocharged Engine yes
Fuel Tank 31.6 gal

Dimensions

Length without Attachment 120.4 in
Width 78 in
Width (with bucket) 80 in
Height with Operator Cab 83.1 in
Height to Bucket Hinge Pin 132 in
Reach @ Maximum Height 38.4 in
Length of track on ground 66.3 in
Track Width 17.7 in
Track Width - Optional 17.7 in
Ground Pressure (Optional Tracks) 4.8 psi
