Bobcat TL519 Telehandler
The Bobcat® TL519 telehandler is compact in size but delivers outsized productivity with a maximum rated capacity of 5,500 pounds and a lift height of 19.6 feet.
- At 6-feet wide and just over 13-feet long, the TL519 is the smallest telehandler in the Bobcat® lineup and can tackle big jobs on small and difficult-to-navigate worksites.
- The TL519 telehandler features a turbocharged, 74-horsepower engine that delivers powerful, high-torque performance and excellent efficiency.
- The advanced hydraulic system and two-stage, low-profile boom support a maximum rated capacity of 5,500 pounds and nearly 20 feet of lift height.
- The T519 telehandler builds upon the Bobcat tradition of operator-centric design with optimal visibility, excellent ergonomics, an efficient HVAC system and enhanced attachment operation.
- The TL519 is ideal for agriculture, construction, landscaping, snow removal, rental and many other jobs that require increased lift height and reach.
- A large selection of standard and hydraulic-powered attachments gives these machines unparalleled versatility.
Get Quote Brochure Promotions Compare Specs Financing Calculator
Starting At $105,159
0% for 36 Months*$3,033/MO
*With 0% Down and Approved Credit.
74 hp
Horsepower
9936 lb
Operating Weight
232 in
Lift Height
Bobcat TL519 Telehandler Specs
** Listed specs based on machine base model. Actual specs may vary depending on model and options **
Specifications
Horsepower 74 hp
Rated Capacity 5512 lb
Lift Height 232 in
Auxiliary Std Flow 21.1 gal/min
Performance
Travel Speed - High 17 mph
Travel Speed - Low 4.3 mph
Rated Capacity 5512 lb
Lift Height 232 in
Lift Height @ Rated Capacity 248 in
Bucket Breakout Force 9,723 lbf
Max Draw Bar Pull 6744 lb
Boom Breakout Force 6,744 lbf
Emissions Tier (EPA) Tier 4
Engine Cooling Liquid
Engine Fuel Diesel
Horsepower 74 hp
Displacement 146 in³
Turbocharged Engine yes
Dimensions
Length 205 in
Length Fork Heel To Rear 157 in
Width 72.1 in
Height 76 in
Height with Operator Cab 76 in
Cab Height with Beacon 82.1 in
Wheelbase 92.9 in
